HICAS automatic panel saw machines deliver precision cutting for solid wood furniture processing, with max thickness of 210mm. Trusted by 500+ global manufacturers for 20+ years. Request a technical demo or ROI analysis today.
Model |
MJ6132-CNC |
MJ6138-CNC |
Sliding table size |
3200*435mm |
3800*435mm |
Max cutting length |
3100mm |
3700mm |
Max cutting width |
1250mm |
1250mm |
Max cutting thickness at 90° |
80/130mm with φ300/φ400mm saw blade |
80/130mm with φ300/φ400mm saw blade |
Max cutting thickness at 45° |
50/90mm with φ300/φ400mm saw blade |
50/90mm with φ300/φ400mm saw blade |
Saw blade tilting |
0-45° electric tilting |
0-45° electric tilting |
Standard saw diameter |
Φ400mm+φ120mm |
Φ400mm+φ120mm |
Max main saw blade |
450mm(there is no blades coming with the machine) |
450mm |
Spindle diameter |
30mm+20mm |
30mm+20mm |
Main saw speed |
4000/6000 rpm |
4000/6000 rpm |
Scoring saw speed |
8000 rpm |
8000 rpm |
Motor power |
5.5kw+1.1kw |
5.5kw+1.1kw |
Standard voltage |
380V 50hz 3ph |
380V 50hz 3ph |
Overall size |
3250*3630*830mm |
3850*3630*830mm |
Plywood packing info |
2700*2200*1300mm 1240kg +4000*450*300mm 160kg |
2700*2200*1300mm 1240kg +4000*450*300mm 160kg |
Note |
Extend and thicken the main machine body |
Extend and thicken the main machine body |
