1.The machine can meet different wood cutting for sofas, ancient buildings, houses, door frames and other products.
2.Welded tempered body， Heavy machine sturcture, more stable.
3.Industrial all-in-one machine, easy operation
4.The cutting list can be transferred to the computer via USB to achieve automatic optimization of cutting, saving time and convenience
5.Can manual edit cutting information on screen , just need to input cutting length, no need to inout raw wood length, Machine will measure automaticly.
6.The machine accept customization, such as wood length and different language requirements according to customers
7.Can add wood scar removal function
Machine parameter
|
Model |
HCS-A12 |
|
Max process length |
2800mm |
|
Min process length |
500mm |
|
Max process width |
150mm |
|
Min process width |
40mm |
|
Max process thickness |
80mm |
|
Cutting angle |
20-90 Degree |
|
Saw blade |
455*30*25.4 |
|
Spindle motor |
7.5KW |
|
Machine size |
10000mm*1400mm*1680mm |
|
Machine weight |
1600KG |
Machine specifation
|
Name |
Brand |
|
Guide |
Germany ROUST |
|
Ball screw rod |
Taiwan HIWIN |
|
Servo X-1000 |
HCFA |
|
Servo Y-1500 |
HCFA |
|
Servo Z-2000 |
HCFA |
|
Fluorescence sensor |
Germany |
|
Photoelectric Sensor |
Germany |
|
Electrical appliances |
Taian |
|
cable |
Jin Huanyu |
|
Sawing spindle |
10P |
|
Machine body |
Welded tempered body |
|
Computer |
Industrial all-in-one machine |
A: Video guidance and English manual can be provided freely, and we provide online support, now all our customers install and operate the machine by themselves with our online support.
A: Most of the spare parts are ready in stock. They will be sent to the buyer directly from our warehouse with original prices.
A: Common spare parts can be delivered by express within one week. Some parts can be purchased locally.
A: 1. Technical support by phone, email or WhatsApp/Skype around the clock. 2. Friendly English version manual and operation video. 3. Engineer available to service machinery overseas.
A: Our machines have been sold to more than 160 countries all over the world, like Russia, Singapore, Uzbekistan, The USA,Malaysia,Peru, Colombia, Vietnam, Slovakia, etc.
A: Our machines can be customized made according to buyers’ request.
A: We provide one-stop shop service of woodworking machines for the buyers. Other kinds of woodworking machines, like sanding machine, CNC router, drilling machine, saw machine can be provided as well.
A: Our system supports common languages like Chinese, English, Russian, Spanish.
