SF2000 Automatic pallet deck Nailing & Stacking Machine

SF2000 AUTOMATIC EUR BLOCK US stringer pallets deck NAILING & STACKING MACHINE

12-Gun Servo · Integrated Stacker · ±2 mm Accuracy

Purpose-built for EUR block US stringer pallets deck— automatic deck-board nailing and stacking in a single machine, up to 1,920 pallets per shift with just 1-2 operators.

12 servo-controlled nail guns · Siemens S7-1200 PLC · automatic nail filling · integrated stacking to 2,800 mm · 4G remote diagnostics.

• Purpose-built for EUR block US stringer pallets deck
• Automatic deck-board nailing + stacking in one machine
• ±2 mm placement accuracy, servo-controlled
• 100 stored recipes — switch pallet specs in minutes
• 150+ HICAS pallet machines delivered worldwide

[ Request Customized Quotation → ]

BUILT TO LAST — ENGINEERED FOR CONTINUOUS PRODUCTION

HEAVY-DUTY 10.7-TONNE FRAME: 10,700 kg of industrial steel built to absorb the impact of 12 nail guns firing continuously — holding ±2 mm accuracy shift after shift.

SERVO-CONTROLLED PRECISION: Servo-driven nailing places every deck-board nail to ±2 mm — the tight, repeatable build quality pallets demand.

LOW-MAINTENANCE DESIGN: Just 5-15 minutes of daily maintenance. Nailing tips rated for 1-3 years. Automatic nail-box filling keeps the machine running.

4G REMOTE DIAGNOSTICS: Built-in 4G module lets HICAS engineers diagnose your machine remotely — faster troubleshooting, less downtime, anywhere in the world.

BUILT FOR HARSH ENVIRONMENTS: Rated -10°C to +45°C, ≤85% humidity. CE certified to 2006/42/EC Machinery Directive (EN ISO 12100, EN 60204-1).

WHY SF2000 FOR YOUR EUR BLOCK PALLET PRODUCTION

PURPOSE-BUILT FOR EUR BLOCK US stringer pallets deck: Engineered specifically for EUR block US stringer pallets deck production — deck-board nailing with the precision and repeatability the European pallet standard demands.

12-GUN AUTOMATIC NAILING + STACKING: 12 servo-controlled nail guns with automatic nail-box filling, plus an integrated stacker — up to 1,920 pallets per shift, all in one machine, with only 1-2 operators.

±2 mm SERVO ACCURACY: Servo-motor control places every deck-board nail to ±2 mm. Board positions — up to 3 deck-board widths per pallet — are fully programmable on the HMI.

100-RECIPE SMART CONTROL: Siemens S7-1200 PLC with 7" touchscreen stores 100 pallet specifications. Switch between your EUR pallet variants in seconds — no mechanical reset.

INTEGRATED STACKING IN ONE MACHINE: Built-in stacker handles up to 2,800 mm stack height and 1,000 kg load — a complete nail-to-stack workflow without a separate stacking line.

LINE-READY INTEGRATION: Profinet integration and 4G remote diagnostics — ready to plug into an automated line and serviced remotely.

CONFIGURED FOR YOUR MARKET

Standard: 380V / 50Hz / 3-Phase.

Customizable at order: 60Hz markets · 220V · 440V.

With 100 stored recipes and HMI-programmable board positions, the SF2000 adapts to your exact EUR US stringer pallets deck specification.

ON COMPONENTS — STRAIGHT TALK

Control and electricals are Siemens S7-1200 PLC and Schneider Electric. Standard pneumatics are AirTac — a proven, widely-serviced brand.

Prefer SMC or Festo? Available as an upgrade on request, so your maintenance team works with the brands they already stock.

PROVEN WORLDWIDE

150+ HICAS SF-series pallet machines delivered across global markets.

Field-proven across diverse climates and power grids — rated for operation from -10°C to +45°C

5-Year TCO vs Premium EUR US stringer pallets deck Nailing Machines

SF2000 is a fully automatic 12-gun EUR block US stringer pallets deck nailing machine with integrated stacking, producing up to 1,920 pallets/shift — matching the output class of premium European machines (Storti, Corali, Viking) with Siemens S7 control, at a fraction of the total cost.

What this means for you:

• ~55-65% lower 5-year TCO at the same full-auto output class
• 12-22 months faster payback — capital freed for expansion
• 2-3 months faster delivery than premium lead times
• Same Siemens S7 control + integrated stacking + 4G diagnostics — savings from manufacturing location, not from cutting features

We don't publish equipment prices because configuration, voltage and options significantly affect final cost. Customized quotation within 24 hours, including a full TCO calculation for your production scale.

[ Request Customized ROI Quotation → ]

Q: What does the SF2000 build?

A: It's purpose-built for EUR block US stringer pallet deck— automatic deck-board nailing with integrated stacking in a single machine.

Q: How many pallets can it produce?

A: 1,440-1,920 pallets per 8h shift, with 12 servo-controlled nail guns and just 1-2 operators.

Q: How accurate is the nailing?

A: ±2 mm placement accuracy, servo-motor controlled, with board positions programmable on the HMI.

Q: Does it stack the pallets too?

A: Yes — an integrated stacker handles up to 2,800 mm stack height and 1,000 kg load, so nailing and stacking happen in one machine.

Q: Can I switch between different EUR pallet variants quickly?

A: Yes. The Siemens S7-1200 PLC stores 100 pallet recipes — switch specs in seconds without mechanical resetting.

Q: What voltage does it use?

A: Standard 380V/50Hz; customizable to 60Hz, 220V and 440V at order.

Q: How is it serviced if there's a problem?

A: A built-in 4G module allows HICAS engineers to diagnose the machine remotely, plus lifetime phone/email/WhatsApp support.

Q: Can I see it make my pallet before ordering?

A: Yes — send your specification for a free sample-run video, typically within 3-5 working days.

Q: What maintenance does it need?

A: Just 5-15 minutes of daily maintenance; nailing tips are rated for 1-3 years.

Q: What are the shipping and delivery details?

A: Ships in 1×40HQ container; 75-90 days from confirmed order.

Q: What payment terms do you accept?

A: 30% T/T deposit with balance terms, LC at sight, and SINOSURE export credit insurance.
